Mechanical

Dimensions

Device: 160.6 x 51.7 x 35.1 mm (6.3 x 2 x 1.4")
Wall mount: 159.3 x 50.3 x 17.5 mm (6.3 x 1.9 x 0.7")
Wedge: 161.1 x 52.1 x 25.7 mm (6.3 x 2.1 x 1")
On-wall mount: 161.1 x 52.1 x 25.75 mm (6.3 x 2.1 x 1")

Weight

Device: 264 g (9.3 oz)
Wall mount: 56 g (2 oz)
Wedge: 33 g (1.2 oz)
On-wall mount: 53 g (1.9 oz)

Enclosure materials

Aluminum alloy, polycarbonate

Mount materials

Wall mount: aluminum alloy
Wedge: polycarbonate
On-wall mount: polycarbonate

Weatherproofing

IPX4

Optics

Sensor

Main camera: 5MP CMOS sensor
Package camera: 8MP CMOS sensor

Lens

Fixed focal length

View angle

Main camera (LDC On): H: 138°, V: 114°, D:   155°
Main camera (LDC Off): H: 160°, V: 117°, D: 160°
Package camera: H: 97.5°, V: 79.4°, D: 118.2°

Night mode

Built-in IR LED illumination and IR cut filter

Video

Video compression

H.264

Resolution

Main camera: 2MP 1600 x 1200 (4:3)
Package camera: 2MP 1600 x 1200 (4:3)

Max. frame rate

30 FPS

System

Processor

Quad-core Arm® Cortex®-A53 based chip

Networking interface

GbE RJ45 port

Power method

PoE

Supported voltage range

37—57V DC

Max. power consumption

7W

LED

Link/activity

Buttons

(1) Ring button
(1) Factory reset

Operating temperature

-30 to 40º C (-22 to 104º F)

Operating humidity

0 to 90% noncondensing

Certifications

CE, FCC, IC

Audio

Microphone

Yes (Can be disabled )

Speaker

Yes

Software

UniFi OS application

UniFi Protect

Mobile app

UniFi Protect iOS™ and Android™

UP-CHIME POE

Mechanical

Dimensions

Device: Ø62 x 54 mm (Ø2.5 x 2.1")
In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5")
On-wall Mount: Ø62 x 20.2 mm (Ø2.5 x 0.8")

Weight

Device: 158 g (5.6 oz)
In-wall mount: 91 g (3.2 oz)
On-wall mount: 28 g (1 oz)

Enclosure materials

Aluminum alloy, polycarbonate

Mount materials

Polycarbonate, zinc alloy

System

Processor

Dual-Core Xtensa®, 32 bit ,400 MIPS

Networking interface

10/100 MbE port

Power method

PoE

Supported voltage range

44—57V DC

Max. power consumption

3.5W

ESD/EMP protection

Air: ± 16kV, contact: ± 8kV

LED

R/G/B/W

Button

Factory reset

Operating temperature

0 to 40° C (32 to 104° F)

Operating humidity

10 to 90% noncondensing

Certifications

CE, FCC, IC

Audio

Speaker

Yes

Buzzer

Yes

Software

Web application

UniFi Protect

Mobile app

UniFi Protect iOS™ and Android™
