Dimensions

Without outdoor cover: 114.5 x 93.6 x 32 mm (4.5 x 3.7 x 1.3")
With outdoor cover: 217 x 94 x 32 mm (8.5 x 3.7 x 1.3")

Weight

Device: 360 g (12.7 oz)
Device with outdoor cover: 395 g (13.9 oz)
DIN rail/wall mounts: 25 g (0.9 oz)

Enclosure material

Polycarbonate, aluminum

Mount material

Wall/pole mount: polycarbonate
DIN rail mount: polycarbonate

Pole mount diameter

1–2" on pipe outer diameter

Wind loading

38.8 N at 200 km/h (8.7 lbf at 125 mph)

Weatherproofing

Device with outdoor cover: IP66

HARDWARE

Management interface

Ethernet
WiFi

Networking interface

(2) GbE RJ45 ports
LTE Category 4 radio
WiFi 4

PoE interface

(1) PoE input
(1) PoE output* (Max. 10W)
*Requires a PoE+ switch.

Power supply

UniFi PoE switch (48—54V DC)
USB Type-C (5V DC)
4-pin* ATX DC power socket (9—30V DC)
*Pin 1 for Power + and Pin 2 for Ground –. Please refer to the Installation Guide for detailed power socket pinout.

Max. power consumption

12.5W

SIM

nano-SIM (4FF)

LTE bands

B2, B4, B5, B12, B13, B14, B25, B26, B66, B71

LTE throughput speed*

Download 150 Mbps / Upload 50 Mbps
*Speed depends on network coverage and performance at the device location.

WiFi standards

802.11 b/g/n, WiFi 2.4G, 20/40 MHz

Max. WiFi TX power

22 dBm

WiFi MIMO

2 x 2

GPS

Yes

Antenna SMA ports

(1) Mobile 1: SMA female connector, supports 1Tx and 1Rx
(1) Mobile 2: SMA female connector, supports 1Rx only
(1) GPS: SMA female connector
(2) WiFi: RP-SMA female connectors
Note: Ensure all SMA / RP-SMA connectors are secured with antennas or the provided caps to maintain weatherproofing.

External antennas

(2) Mobile/LTE antennas with SMA male   connectors
(1) GPS antenna with SMA male connector
(2) WiFi antennas with RP-SMA male connectors

LED

Status: blue/white

Button

Factory reset

Mounting

DIN rail/wall/pole mount (Included)

Ambient operating temperature

-40 to 70° C (-40 to 158° F)

Ambient operating humidity

5 to 95% noncondensing

Certifications

FCC, IC, PTCRB, GCF, AT&T, T-Mobile, Verizon, Wi-Fi Alliance®

SUPPORTED WIFI DATA RATES

802.11b

1, 2, 5.5, 11 Mbps

802.11g

6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)

6.5 Mbps to 300 Mbps (MCS0 - MCS7, HT 20/40)
