Image Sensor

1/3” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Slow Shutter

Yes

Minimum Illumination

0.005 Lux; 0 Lux with IR/white light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Day/Night/Auto/Schedule-Switch

Zoom

3x Mixed Zoom

LENS

Focal Length

4-12 mm (Mixed Zoom)

Aperture

F1.6

FOV

Diagonal FOV: 100°, Horizontal FOV: 84°, Vertical FOV: 46°

Lens Mount

M12*P 0.5

PTZ

Pan/tilt Range

Pan: 0° to 332°, Tilt: 0° to 120°

Pan/tilt Speed

Pan Speed:

Configurable from 1° to 55°/s; Preset Speed: 55°/s

Tilt Speed:

Configurable from 1° to 40°/s, Preset Speed 40°/s

Presets

300

Patrol Scan

8 patrols, up to 8 presets for each patrol

Power-off Memory

Yes;

Auto restore to previous PTZ and lens status after power failure

Park Action

Yes;

Preset; Patrol Scan

3D Positioning

Yes

VIDEO

Max. Resolution

2560 X 1440

Main Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Sub-Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Bit Rate Control

CBR, VBR

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264

Sub-Stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main Stream Supported

H.265 Type

Main Profile

H.265+

Main Stream Supported

Video Bit Rate

Main Stream: 256 Kbps to 4 Mbps

Sub-Stream: 64 Kbps to 512 Kbps

ILLUMINATOR

IR LED

Quantity: 1

Range: 30m

Wavelength: 850nm

White LED

Quantity: 3

Range: 30m

Illuminator On/Off Control

Auto/Scheduled/Always on/Always off

ANGLE ADJUSTMENT (MANUAL)

Range

Pan: 0° to 332°, Tilt: 0° to 120°


Image Settings

Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software

Image Enhancement

BLC/3D DNR/HLC/SmartIR

Wide Dynamic Range

DWDR

SNR

≥ 52 dB

Image Parameters Switch

Yes

Privacy Mask

Up to 4 Masks

ROI

1 Region

OSD Setting

Yes

AUDIO

Audio Communication

Two-Way Audio

Audio Input

Yes

Audio Output

Yes

Audio Compression

Yes

Audio Sampling Rate

8KHz

Environment Noise Filtering

Yes

Audio Bit Rate

64 Kbps(G.711 alaw)

NETWORK

Security

Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

Protocol

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP,   SSL/TLS

Network Storage

NAS (NFS, SMB/ CIFS)

API

Open Network Video Interface (Profile S)

Simultaneous Live View

3 Main Streams & 3 Sub-Streams

Client

VIGI App, VIGI Security Manager, VIGI NVR, Web

Web Browser

Google Chrome® 57 and above Firefox® 52 and above

Safari® 11 and above

Microsoft® Edge 91 and above

Cloud

Yes

ONVIF

Yes

INTERFACES

Network Interface

1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE

Alarm

N/A

Reset Button

Yes

Power

DC Power Port

On-board Storage

Built-In Memory Card Slot, Support MicroSD Card, up to 256 GB

Built-in Microphone

Yes; Records Anything Going on within a 15-ft Radius of the Camera

Built-in Speaker

Yes

Audio

N/A

ALARM AND EVENT MANAGEMENT

Smart Event

Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection

Basic Event

Motion Detection, Video Tampering Detection, Exception (Illegal Login)

Alarm Linkage

Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing

Linkage Method

N/A

Output Notification

Message Push

GENERAL

Package Contents

VIGI Network Camera

Quick Start Guide

Waterproof Cable Attachments

Mounting Accessories

Operating Temperature

-30–60 °C

Storage Temperature

-40–60 °C

Storage Humidity

95% or Less (Non-Condensing)

Operating Humidity

95% or Less (Non-Condensing)

Material

Plastic

Net Weight

0.43 Kg

Gross Weight

0.66 Kg

Power Supply

12V DC ± 5%, 5.5mm Coaxial Power Plug

PoE (802.3at, class 4)

Power Consumption

Maximum: 14 W

Typical (Day Mode): 2.9 W

Typical (Night Mode with IR LED): 5.7 W

Typical (Night Mode with White LED): 6.1 W

Protection

IP66

Product Dimensions (L x W x H)

139*136*107 mm

Certifications

CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
