Image Sensor

1/3” Progressive Scan CMOS Starlight Sensor

Lens

Focal Length: 4 mm

Aperture: F2.0

Field of View: 88° (Diagonal), 75°(Horizontal), 41°(Vertical)

Motion Range

Pan Mechanical Range: 340° (360° Pan Coverage)

Tilt Mechanical Range: 69° (110° Tilt Coverage)

Night Vision

850 nm IR LED (30 ft / 10 m)

Interface & Button

1× RESET Button

1× MicroSD Card Slot (Up to 512GB)

VIDEO & AUDIO

Maximum Resolution

2K QHD 4MP (2560 x 1440px)

Frame Rate

15/20/25/30 fps (Default 15fps)

Digital Zoom

12x

Video Compression

H.264　

Live View

Yes

Image Enhancement

3D DNR

WDR

Audio Input & Output

Built-in Microphone and Speaker　

Audio Communication

Two-Way Audio with Noise Cancellation

Siren Volume

99dB (Level measured at 4-inch/10-cm distance)

STORAGE

Local Storage

MicroSD Card Slot on Camera (Up to 512 GB)*

Cloud Storage

Tapo Care Cloud Storage Services (Subscription required)*

DETECTION AND NOTIFICATIONS

AI Detection

Motion Detection

Person Detection

Line-Crossing Detection

Tamper Detection

BabyCry Detection

Vehicle Detection

Pet Detection

Meow Detection

Bark Detection

Glass-Breaking Detection

Activity Zones

Yes

Output Notification

System Notification

System Notification with Snapshot (Tapo Care Services)

NETWORK

Network Connectivity

Connect via Wi-Fi

Wireless Connectivity

IEEE 802.11b/g/n, 2.4 GHz Wi-Fi

Ethernet Port

/

RTSP

Yes

ONVIF

Yes

SECURITY

Security

On-Device Machine Learning

128-bit AES Encryption with SSL/TLS

WPA/WPA2-PSK

POWER

Power Source

9V DC Power Adapter

Input Voltage

100-240 V, 50/60 Hz　

Output Voltage

9V, 0.6 A (DC Power)　

GENERAL

Smart Integration

Google Assistant, Amazon Alexa

System Requirements

Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher

Mounting Options

Tabletop

Ceiling-Mounted　

Operating Temperature

0℃~40℃

Storage Temperature

-20℃~60℃

Operating Humidity

10%~90% RH, Non-condensing

Storage Humidity

5%~90% RH, Non-condensing

Dimensions

3.36 × 3.42 × 4.63 in (85.4 × 86.8 × 117.7 mm)

Package Contents

TC72 Camera

Power Adapter

Quick Start Guide

Mounting Screws

Mounting Template

Camera Base

Mounting Anchors 　

Notes

* microSD Card purchased separately.

* Tapo Care subscribe at: https://www.tapo.com
