Standards and Protocols

• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q

• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP

Interface

• 2× 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)

• 1× 1GE SFP WAN/LAN Ports

• 8× 1GE RJ45 WAN/LAN Ports

• 1× RJ45 Console Ports

• 2× USB Ports (Connecting 4G/3G Modem as WAN Backup)

Network Media

• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)

EIA/TIA-568 100Ω STP (Max 100 m)

• 100BASE-TX: UTP category 5, 5e cable (Max 100 m)

EIA/TIA-568 100Ω STP (Max 100 m)

• 1000BASE-T: UTP category 5e, 6 cable (Max 100 m)

Fan Quantity

2

Button

Reset Button

Power Supply

Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)

PoE Budget

-

Flash

4MB SPI NOR + 256 MB NAND

DRAM

4 GB DDR4

LED

PWR, SYS, WAN, LAN, USB, FAN

Dimensions ( W x D x H )

17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)

Protection

4 kV surge protection

Enclosure

Steel

Mounting

Rack Mountable

Max Power Consumption

26.36 W (with USB 3.0 connected)

19.12 W (without USB 3.0 connected)

PERFORMANCE

Concurrent Session

2,300,000

New Sessions /Second

20,000

NAT (Static IP)

Upload: 9445.82 Mbps

Download: 9449.26 Mbps

NAT(DHCP)

Upload: 9426.83 Mbps

Download: 9426.20 Mbps

NAT(PPPoE)

Upload: 9413.96 Mbps

Download: 9102.01 Mbps

NAT (L2TP)

Upload: 4230.62 Mbps

Download: 4169.53 Mbps

NAT (PPTP)

Upload: 3933.86 Mbps

Download: 3821.97 Mbps

64 Byte Packet Forwarding Rate

Upload: 1080 Mbps

Download: 1030 Mbps

IPsec VPN Throughput

SHA1-AES256: 2140.45 Mbps

SHA2-AES256: 2080.20 Mbps

OpenVPN

1665.64 Mbps

L2TP VPN Throughput

Unencrypted: 5013.50 Mbps

Encrypted: 2274.74 Mbps

PPTP VPN Throughput

Unencrypted: 3933.86 Mbps

Encrypted: 3821.97Mbps

SSL VPN Throughput

1511.10 Mbps

66 Byte Packet forwarding rate

-

1,518 Byte Packet forwarding rate

Upload: 9970 Mbps

Download: 9970 Mbps

BASIC FUNCTIONS

WAN Connection Type

• Static/Dynamic IP

• PPPoE

• PPTP

• L2TP

• 6to4 Tunnel

• Pass-Through

• Mobile Broadband: 4G/3G modem for backup via USB port

MAC Clone

Modify WAN/LAN MAC Address*4

DHCP

• DHCP Server/Client

• DHCP Address Reservation

• Multi-net DHCP

• Multi-IP Interfaces

IPv6

WAN Connection

VLAN

802.1Q VLAN

IPTV

IGMP v2/v3 Proxy

ADVANCED FUNCTIONS

ACL

IP/Port/Protocol/Domain Name Filtering

Advanced Routing

Static Routing

Policy Routing

Bandwidth Control

• IP/Port-based Bandwidth Control

• Guarantee & Limited Bandwidth

Load Balance

• Intelligent Load Balance

• Application Optimized Routing

• Link Backup (Timing*5, Failover)

• Online Detection

NAT

• One-to-One NAT*5

• Multi-Net NAT

• Virtual Server

• Port Triggering*5

• NAT-DMZ

• FTP/H.323/SIP/IPSec/PPTP ALG

• UPnP

Security

• SPI Firewall

• VPN Passthrough

• FTP/H.323/PPTP/SIP/IPsec ALG

• DoS Defence, Ping of Death

• Local Management

Session Limit

IP-based Session Limit

VPN

SSL VPN

• SSL VPN Server

• SSL VPN Client

• 500 OpenVPN Tunnels

IPsec VPN

• 300 IPSec VPN Tunnels

• LAN-to-LAN, Client-to-LAN

• Main, Aggressive Negotiation Mode

• DES, 3DES, SHA1, SHA2, AES128, AES192, AES256 Encryption Algorithm

• IKE v1/v2

• MD5, SHA1 Authentication Algorithm

• NAT Traversal (NAT-T)

• Dead Peer Detection (DPD)

• Perfect Forward Secrecy (PFS)

PPTP VPN

• PPTP VPN Server

• PPTP VPN Client (32)*6

• 300 Tunnels (Shared with L2TP)

• PPTP with MPPE Encryption

L2TP VPN

• L2TP VPN Server

• L2TP VPN Client (32)*6

• 300 Tunnels (Shared with PPTP)

• L2TP over IPSec

OpenVPN

• OpenVPN Server

• OpenVPN Client (10)*6

• 110 OpenVPN Tunnels

SECURITY

Filtering

• WEB Group Filtering*5

• URL Filtering

• Web Security*5

ARP Inspection

• Sending GARP Packets*5

• ARP Scanning*5

• IP-MAC Binding*5

Attack Defense

• TCP/UDP/ICMP Flood Defense

• Block TCP Scan (Stealth FIN/Xmas/Null)

• Block Ping from WAN

Access Control

Source/Destination IP Based Access Control

AUTHENTICATION

Web Authentication

• No Authentication

• Simple Password*2

• Hotspot（Local User / Voucher*2 / SMS*2 / Radius*2）

External Radius Sever

• External Portal Sever*2

• Facebook Check-In*2

• Instagram Follow*2

MANAGEMENT

Omada App

Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management

• Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

• Omada Cloud-Based Controller

Cloud Access

Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.

Service

Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)

Maintenance

• Web Management Interface

• Remote Management

• Export & Import Configuration

• SNMP v1/v2c/v3

• Diagnostics (Ping & Traceroute)*5

• NTP Synchronize*5

• Syslog Support

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller.

Management Features

• Automatic Device Discovery

• Intelligent Network Monitoring

• Abnormal Event Warnings

• Unified Configuration

• Reboot Schedule

• Captive Portal Configuration

OTHERS

Certification

CE, FCC, RoHS

Package Contents

• Omada 10G Multi-WAN Security Gateway ER8411

• Power Cord

• Rack-Mount Kit

• Quick Installation Guide

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or Linux

Environment

• Operating Temperature: 0–40 ℃ (32–104 ℉);

• Storage Temperature: -40–70 ℃ (-40–158 ℉)

• Operating Humidity: 10–90% RH non-condensing

• Storage Humidity: 5–90% RH non-condensing

Notes

1. At least one WAN/LAN port needs to function as a LAN port.

2. These functions require the use of Omada Hardware Controller, Software Controller, or Cloud-Based Controller.

3. Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller. Please go to Omada Cloud-Based Controller Product List to find all the models supported by Omada Cloud-Based Controller.

4. LAN MAC Address can be modified only in Standalone Mode.

5. These functions are supported only in Standalone Mode.

6. ER8411 can work as a VPN client and can connect with up to 32 PPTP/L2TP VPN servers and 10 OpenVPN servers.
