Standards

Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds

AX1800
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax)

WiFi Capacity

High

Dual-Band
Distribute devices to different bands for optimal performance

MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients

OFDMA
Simultaneously communicates with multiple WiFi 6 clients

4 Streams
More than enough bandwidth for connected devices

Working Modes

Router Mode
Access Point Mode

HARDWARE

Processor

1.5 GHz Quad-Core CPU

Performance

Microphone
Quadruple microphone array

Speaker
5 W full frequency speaker with double bass passive diaphragm

Ethernet Ports

2× Gigabit Ports

*Per Deco Voice Unit
Supports WAN/LAN auto-sensing

Buttons

1 Reset Button
1 Mute Button
1 Action Button
2 Volume Buttons

Power

12 V ⎓ 1.5 A

SECURITY

WiFi Encryption

WPA-Personal
WPA2-Personal
WPA3-Personal

Network Security

SPI Firewall
Access Control

HomeShield Security

Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner

Guest Network

1× 5 GHz Guest Network
1× 2.4 GHz Guest Network

SOFTWARE

Protocol

IPv4
IPv6

Parental Controls

HomeShield Parental Controls

Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports

WAN Types

Dynamic IP
Static IP
PPPoE
PPTP
L2TP

Quality of Service

HomeShield QoS

QoS by Device

Cloud Service

OTA Firmware Upgrade
TP-Link ID
DDNS

NAT Forwarding

Port Forwarding
UPnP

IPTV

IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN

DHCP

Address Reservation
DHCP Client List
Server

DDNS

TP-Link

Management

Deco App

PHYSICAL

Dimensions (W×D×H)

4.13 × 4.13 × 6.69 in
(105 × 105 × 170 mm)

Package Contents

Deco Voice X20 (1-pack)
1 Deco Voice X20 unit
1 RJ45 Ethernet cable
1 Power adapter
1 Quick Installation Guide

OTHERS

System Requirements

Android 4.4 or later
iOS 9.0 or later

Certifications

CE, EAC, FCC, IC, RoHS, RCM

Environment

Operating Temperature: 0°C~40°C   (32°F~104°F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH

TEST DATA

WiFi Transmission Power

CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm(2.4 GHz)
<30 dBm(5 GHz)
