Interface

3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 Micro SIM Card Slot

Button

WPS/Reset Button, Wireless On/Off Button, Power On/Off Button

External power supply

12V/1A

Dimensions ( w x d x h )

7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm)

Antenna

2 Internal 4G LTE Antennas,

2 Fixed External WiFi Antennas

Compatibility

NBN - Fibre to the Premises (FTTP) - Wireless Router Mode.

NBN - Fibre to the Home (FTTH) - Wireless Router Mode.

For further information on NBN connections please visit:     http://www.nbnco.com.au/learn-about-the-nbn/network-technology.html

Interface

3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 Micro SIM Card Slot

WIRELESS FEATURES

Wireless standards

IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz

Frequency

2.4GHz and 5GHz

Signal rate

300Mbps at 2.4GHz, 433Mbps at 5GHz

Reception sensitivity

5GHz:

11a 54M: -74dBm

11ac HT20: -67dBm

11ac HT40: -64dBm

11ac HT80 : -60dBm

11n HT20: -71dBm

11n HT40: -70dBm

2.4G

11g 54M: -76dBm

11n HT20: -73dBm

11n HT40: -67dBm

Transmit power

CE:<20dBm(2.4GHz), <23dBm(5GHz)

Wireless functions

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

Wireless security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

Network type (v2)

4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)

TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500MHz)

3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)

2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz)

Network type (v3)

4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)

TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500MHz)

3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)

Network type

4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)

TDD-LTE B38/B40 (2600/2300MHz)

3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)

2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz)

SOFTWARE FEATURES

Quality of service

Bandwidth Control

Operating modes

3G/4G Router, Wireless Router

WAN type

Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)

Management

Access Control, Local Management, Remote Management

DHCP

Server, Client, DHCP Client List, Address Reservation

Port forwarding

Virtual Server, Port Triggering, UPnP, DMZ

Dynamic DNS

DynDns, NO-IP

VPN pass-through

PPTP VPN, IPSec VPN , OpenVPN

VPN

PPTP VPN, IPSec VPN , OpenVPN

Access control

Parental Control, Local Management Control

Firewall security

DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding

Protocols

Supports IPv4 and IPv6

Guest network

2.4GHz guest network x 1, 5GHz guest network x 1

IPSEC VPN

Supports up to 10 IPSec VPN tunnels

OTHERS

Certification

CE, RoHS

Package contents

AC750 Wireless Dual Band 4G LTE Router

Archer MR200

RJ45 Ethernet Cable

Power Adapter

Quick Installation Guide

System requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare,   UNIX or Linux

Internet Explorer 11, Firefox 12.0, Chrome 20.0,

Safari 4.0 browsers or higher, or other Java-enabled browsers

Micro SIM Card

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
