TP-Link 5-Port Gigabit Easy Smart Switch (TL-SG105E)

TP-Link  5-Port Gigabit Easy Smart Switch (TL-SG105E)
  • 34063_thumb_P_1563235157446
  • 34063_thumb_P_1563235173606
  • 34063_thumb_P_1563235173337
$24.0 Question Mark
Was: $28.0  WAS Tips    14% Off!
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Click & Collect   Question Mark

Your store is set to:

Loading... Contact Store

   Same Day Dispatch   Question Mark

Order within 11hrs and 11mins

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    TP-Link 5-Port Gigabit Easy Smart Switch (TL-SG105E)
  • Model Number:
    TL-SG105E
  • Brand:
  • Warranty Period:
    5 Year

Description

1657522929401192





SPECIFICATIONS:

HARDWARE FEATURES

Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE   802.1p

Interface

5 10/100/1000 Mbps RJ45 Ports
  AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  EIA/TIA-568 100Ί STP   (maximum 100m)
  100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  EIA/TIA-568 100Ί STP   (maximum 100m)
  1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  EIA/TIA-568 100Ί STP   (maximum 100m)

Fan Quantity

Fanless

Power Supply

External Power Adapter (Output: 5 VDC/ 0.6 A)

Dimensions ( W x D x H )

3.9 × 3.9 × 1.0 in. (100 × 98 × 25 mm)

Max Power Consumption

2.82 W (220 V/ 50 Hz)

Max Heat Dissipation

9.62 BTU/h

PERFORMANCE

Packet Forwarding Rate

7.4 Mpps

MAC Address Table

2 K

Packet Buffer Memory

1 Mb

Jumbo Frame

16 KB

SOFTWARE   FEATURES

Quality of Service

Support Port-based/802.1p/DSCP priority
  Support 4 priority queues
  Rate Limit
  Storm Control

L2 Features

IGMP Snooping V1/V2/V3
  Static Link Aggregation
  Port Mirroring
  Cable Diagnostics
  Loop Prevention

VLAN

Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
  MTU/Port/Tag VLAN

Transmission Method

Store-And-Forward

OTHERS

Certification

FCC, CE, RoHS

Package Contents

TL-SG105E
  Power Adapter
  Installation Guide
  Rubber Feet

System Requirements

MicrosoftÂŽ WindowsÂŽ for running Utility

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)
  Storage Temperature: -40℃~70℃ (-40℉~158℉)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing
