Image Sensor

1/3” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Slow Shutter

Yes

Minimum Illumination

0 lux with IR/white Light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Day/Night/Auto/Schedule-Switch

Lens

Fixed focal lens (4 mm)

Aperture

4 mm: F1.6

Lens Mount

M12

Viewing Angle

(4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°

IR Working Distance

30m

Illumination Distance

30 m

Digital Noise Reduction

3D DNR

WDR

DWDR

Weatherproof Rating

IP66

LENS

Type

Fixed Focal Lens

Focal Length

4 mm

Aperture

F1.6

FOV

Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°

Lens Mount

M12

DORI Distance

Detect: 80 m (262 ft)

Observe: 33 m (109 ft)

Recognize: 16 m (52 ft)

Identify: 8 m (26 ft)

VIDEO

Max. Resolution

2560 X 1440

Main Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Sub-Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Bit Rate Control

CBR, VBR

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264

Sub-Stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main Stream Supported

H.265 Type

Main Profile

H.265+

Main Stream Supported

Video Bit Rate

Main Stream: 256 Kbps to 4 Mbps

Sub-Stream: 64 Kbps to 512 Kbps

ILLUMINATOR

IR LED

Quantity: 2

Range: 30m

Wavelength: 850nm

White LED

Quantity: 2

Range: 30m

Illuminator On/Off Control

Auto/Scheduled/Always on/Always off

ANGLE ADJUSTMENT (MANUAL)

Range

Pan: -90° to 90°

Tilt: -90° to 90°


Image Settings

Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°)

Image Enhancement

BLC/3D DNR/HLC/SmartIR

Wide Dynamic Range

DWDR

SNR

≥ 52 dB

Image Parameters Switch

Yes

Privacy Mask

Up to 4 Masks

ROI

1 Region

OSD Setting

Yes

AUDIO

Audio Communication

Two-Way Audio

Audio Input

Yes

Audio Output

Yes

Audio Compression

Yes

Audio Sampling Rate

8KHz

Environment Noise Filtering

Yes

Audio Bit Rate

64 Kbps(G.711 alaw)

NETWORK

Security

Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

Network Storage

NAS (NFS, SMB/ CIFS)

Protocol

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP,   SSL/TLS

Wireless Rate

11 Mbps (802.11b)

54 Mbps (802.11g)

150 Mbps (802.11n)

Frequency

2.4 GHz

Wireless Security

WPA/WPA2-PSK

API

ONVIF

Simultaneous Live View

3 Main Streams & 3 Sub-Streams

Client

VIGI App, VIGI Security Manager, VIGI NVR, Web

Web Browser

Google Chrome® 57 and above

Firefox® 52 and above

Safari® 11 and above

Microsoft® Edge 91 and above

Cloud

Yes

ONVIF

Yes

INTERFACES

Network Interface

1 RJ45 10/100M Self-Adaptive Ethernet Port

Audio Input

Built-in Microphone

Audio Output

Built-in Speaker

Alarm

N/A

Reset Button

Yes

Power

DC Power Port

Button

Reset Button

On-board Storage

Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB

Built-in Microphone

Yes; Records Anything Going on within a 15-ft Radius of the Camera

Built-in Speaker

Yes

Audio

N/A

ALARM AND EVENT MANAGEMENT

Smart Event

Area Intrusion Detection, Line-Crossing Detection, People Detection

Basic Event

Motion Detection, Video Tampering Detection, Exception (Illegal Login)

Alarm Linkage

Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing

Linkage Method

N/A

Output Notification

Message Push

GENERAL

Package Contents

VIGI Network Camera

Quick Start Guide

Waterproof Cable Attachments

Power Adapter

Mounting Accessories

Operating Temperature

-30–60 °C

Storage Temperature

-40–60 °C

Storage Humidity

95% or Less (Non-Condensing)

Operating Humidity

95% or Less (Non-Condensing)

Dimensions( H X W X D )

80 × 70.6 × 173.4 mm

Material

Plastic

Weight

195g

General Features

Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening

Net Weight

0.31 Kg

Gross Weight

0.6 Kg

Power Consumption

12V DC: Max 7W

Power Supply

12V DC ± 5%, 5.5mm Coaxial Power Plug

Antenna

Quantity: 2

Type: 2.4GHz Welded Dipole Omni-Directional Antenna

Gain: 2.0dBi

Protection

IP66

Product Dimensions (L x W x H)

80× 173 × 71 mm (excluding antennas)

Certifications

CE, RCM, BSMI, VCCI, RoHS, NTRA, KC

WIRELESS

Standards

IEEE 802.11b/g/n

WiFi Channels

UN: 1-13

US: 1-11

Frequency

2.4 GHz

Wireless Transmit Power

High

Auto Wireless Channel

N/A

Wireless Statistics

N/A

Throughput Mornitor

N/A

Radio Bandwidth

Auto: N/A

20M: Yes

40M: Yes

Wireless Rate

11Mbps(802.11b)

54Mbps(802.11g)

150Mbps(802.11n)

Wireless Security

PWPA/WPA2-PSK

Wireless Mode

AP, AP Client

VIDEO/IMAGE

Video Compression

Main stream: H.265+/H.265/H.264+/H.264

Sub-Stream: H.265/H.264

Frame Rate & Resolutions

Main Stream

Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080

Sub-Stream

Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution: 640x480, 352x288, 320x240

Video Streaming

Main Stream

Sub-Stream

Image Settings

Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software

Image Enhancement

BLC/3D DNR/Prevent Overexposure to Infrared Light

Video Bit Rate

Main Stream: 256 Kbps to 4 Mbps

Sub-Stream: 64 Kbps to 512 Kbps

SMART FEATURE-SET

Smart Event

Area Intrusion Detection, Line-Crossing Detection, Human Detection

Basic Event

Motion Detection, Camera Tampering Detection, Exception ( illegal login)

Linkage Method

Trigger Notification: ONVIF, HTTPS

Region of Interest

1 Region
