TP-Link 16-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+ (TL-SG1016PE)

TP-Link 16-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+ (TL-SG1016PE)
  • 38830_thumb_P_1494293594475
$139.0 Question Mark
Was: $189.0  WAS Tips    Save $50.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Click & Collect   Question Mark

Your store is set to:

Loading... Contact Store

   Same Day Dispatch   Question Mark

Order within 11hrs and 51mins

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    TP-Link 16-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+ (TL-SG1016PE)
  • Model Number:
    TL-SG1016PE
  • Brand:
  • Warranty Period:
    5 Year

Description




TL-SG1016PE
 16 10/100/1000Mbps RJ45 ports
 Equipped with 8 PoE+ supported ports to transfer data and power over a single cable
 Works with IEEE 802.3af/at compliant devices, expanding home and office networks
 Innovative energy-efficient technology reduces power output by up to 75%*
 Plug and play design, no configuration required

 *Actual data may vary in different usage environment.



Official Product LinkOpen Link
Interface16 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100© STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100© STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100© STP (maximum 100m)
SpecificaitonsFan Quantity 1
Power Supply 100-240VAC, 50/60Hz
Power Consumption Maximum (PoE on): 124.4W (220V/50Hz)
Maximum (PoE off): 14.4W (220V/50Hz)
PoE+ Ports(RJ45) 8 Ports
Backbound Bandwidth 32 Gbps
Mac Address Table 8K
Buffer Size 1.5 Mbits
Dimensions ( W x D x H ) 11.6*7.1*1.7 in. (294*180*44 mm)
Transfer MethodStore-And-Forward
Advanced FunctionsCompatible With IEEE 802.3af/at Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
CertificationFCC, CE, RoHS
Package ContentsTL-SG1016PE
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet
Consumption9.5 watts (max. no PD connected)
140.1 watts (max. with 126w PD connected)
EnvironmentOperating Temperature: 0ƒ~40ƒ (32‰~104‰)
Storage Temperature: -40ƒ~70ƒ (-40‰~158‰)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

* Specifications are subject to change without notice.
  * Specifications may vary.
  * The product picture(s) is only for your reference, it may differ from the actual product.
