IEEE Standards

IEEE802.11b/g/n, IEEE 802.3, 802.3u,IEEE 802.1Q

xDSL Standard&Protocol

ITU G.993.2, Up to 17a /30a profile

ITU-T G.993.5 (G.vector)

ITU-T G.998.4 (G.INP)

ITU-T G.993.2 VDSL2

ITU-T G.993.1 VDSL

ITU-T G.992.1(G.DMT)

ITU-T G.992.2(G.Lite)

ITU-T G.992.4.ADSL2 (G.Lite bis)

ITU-T G.992.3 ADSL2(G.DMT.bis)

ITU-T G.992.5 ADSL2✚

Interfaces

3 *10/100 RJ45 LAN Ports

1 *10/100 RJ45 LAN/WAN Port

1 *RJ11 Port

Dimension

157.8 × 105.2 × 29.4mm(W * D * H)

Button

WPS

RST

Power

External Power Supply

9V 1A

LED Indicator

PWR,Internet,WLAN,LAN ,DSL

Certification

CE, RoHS，VOC

SOFTWARE

Protocols

Supports IPv4

ATM/PPP Protocols

ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs

WAN Connection

PPPoE , Dynamic IP, Static IP, Bridge

Business Type

Internet, IPTV

Services

DDNS，Port Forwarding，DMZ，IPTV

DHCP Server

DHCP Server,Client List, Address Reservation

Quality of Service

-

Management

Web Based device Configuration(HTTP),

Web Based Firmware Upgrade, Diagnostic Tools

Advanced Functions

Routing,Port Mapping(Grouping), Static Routing, DNS proxy, IGMP

Firewall

IP and Port Filtering，URL Blocking，DDOS

TR069

-

IPv6

-

USB Sharing

-

VoIP

-

Others functions

ALG,Ping Diagnostics,System Log,DSL Statistics

WIRELESS

Wireless Standard

IEEE 802.11b/g/n 2.4GHz

Bandwidth

20M/40M

Channel Range

2.4G:Auto,CH1-CH13

Antenna

2* 5 dBi Antenna

Wireless Speed

300Mbps at 2.4GHz

Transmission Power

2.4GHz <20dBm(EIRP)

Wireless Functions

Enable/Disable Wireless Radio,Guest network，Access Control,WPS

Wireless Security

None, WPA,WPA2,WPA/WPA2

ENVIRONMENT

Storage Temperature

-40°c ~ 70°c

Operation Temperature

0℃~40℃ (32℉   ~104℉)

Operating Humidity

10% ~ 90% （Non-condensing）

Storage Humidity

5% ~ 90% (Non-condensing)

OTHERS

Package Contents

N300 Wi-Fi VDSL/ADSL Modem Router*1

External Splitter*1

Power Adapter*1

RJ11 DSL Cable*2

RJ45 Ethernet Cable*1

Quick Installation Guide*1
