CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1 |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out |
HDCP | HDCP 1.4 (HDMI/DisplayPort), HDCP 2.2 (HDMI/DisplayPort) |
PICTURE/DISPLAY |
|
Panel Size | 34 inch/86.36 cm |
Aspect ratio | 21:9 |
Backlight type | VA, 1500 R (curvature) |
Pixel pitch | 0.23175 x 0.23175 mm |
Brightness | 300 cd/m² |
Display colours | Colour support: 1.07 billion colours (10 bits)* |
Colour gamut (typical) | Adobe RGB 90%; DCI-P3:94%, sRGB: 125%, NTSC 105%* |
Contrast ratio (typical) | 4000:1 |
SmartContrast | Mega Infinity DCR |
Response time (typical) | 1 ms (Grey to Grey)* |
Viewing angle | 178º (H)/178º (V) @ C/R > 10000 |
Picture enhancement | SmartImage game |
Maximum resolution | 3440 x 1440 @ 180 Hz (DP), 8 bits; 3440 x 1440 @ 100 Hz (HDMI), 8 bits |
Effective viewing area | 797.22 (H) x 333.72 (V) mm — at a 1500 R curvature* |
Scanning Frequency | 30–255 kHz(H)/48–180 Hz(V) |
sRGB | Yes |
Delta E | <2 (sRGB) |
Flicker-free | Yes |
Pixel Density | 109.68 PPI |
LowBlue Mode | Yes |
Display Screen Coating | Anti-glare, 25%, 3H |
SmartUniformity | 93~105% |
Low Input Lag | Yes |
EasyRead | Yes |
Adaptive sync | Yes |
HDR | Supported HDR 10 |
Backlight type | W-LED |
Smart MBR | 0.5 ms* |
Smart Crosshair | Yes |
Shadow Boost | Yes |
CONVENIENCE |
|
Plug and Play Compatibility | DDC/CI Mac OS X sRGB Windows 11/10 |
User convenience | Power On/Off Menu/OK Input/Up Game Settings/Down SmartImage game/Back |
OSD Languages | Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Spanish Simplified Chinese Swedish Turkish Traditional Chinese Ukrainian |
Other convenience | Kensington lock VESA mount (100 x 100 mm) LowBlue Mode MultiView 2 x Devices PIP/PBP mode |
STAND |
|
Tilt | -5/20 degree |
POWER |
|
Power supply | Internal 100–240 VAC, 50–60 Hz |
Off mode | 0.3 W (typ.) |
On mode | 31.0 W (typ.) |
Standby mode | 0.5 W (typ.) |
Power LED indicator | Operation - White Standby mode - White (flashing) |
DIMENSIONS |
|
Packaging in mm (W x H x D) | 930 x 480 x 188 mm |
Product without stand (mm) | 808 x 369 x 69 mm |
Product with stand (max height) | 808 x 464 x 251 mm |
WEIGHT |
|
Product with packaging (kg) | 9.47 kg |
Product with stand (kg) | 7.33 kg |
Product without stand (kg) | 6.50 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m) |
Temperature range (operation) | 0°C to 40 °C |
MTBF | 50,000 hour(s) |
Relative humidity | 20%-80% |
Temperature range (storage) | -20°C to 60°C |
SUSTAINABILITY |
|
Environmental and energy | RoHS |
Post-consumer recycled plastics | 85%* |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark TUV/ISO9241-307 TUV-BAUART EAC EAEU RoHS UKCA EMF FCC ICES-003 cETLus |
OTHERS |
|
Notes | * Radius of the arc of the display curvature in mm * Display colours: 10 bits can be reached by DP @ 165 Hz * Response time value equal to SmartResponse. * Adobe RGB and DCI-P3 Coverage based on CIE1976, sRGB Area based on CIE1931, NTSC Area based on CIE1976. * Smart MBR adjusts brightness for blur reduction, so you cannot adjust brightness while Smart MBR is turned on. To reduce motion blur, the LED backlight will strobe synchronously with each screen refresh, which may cause a noticeable change in brightness. * Smart MBR is a gaming-optimised mode. Turning on Smart MBR may cause noticeable screen flickering. We recommended turning it off when you are not using the gaming function. * This monitor strives for sustainability: the stand's feet are made with 35% recycled plastic and the monitor's chassis is made up of 85% post-consumer recycled plastic. |
