LCD panel   type

IPS   technology

Backlight   type

W-LED system

Panel Size

23.8 inch /   60.5 cm

Display   Screen Coating

Anti-Glare,   3H, Haze 25%

Effective   viewing area

527.04 (H) x   296.46 (V)

Aspect ratio

16:9

Maximum   resolution

1920 x 1080 @   75 Hz*

Pixel Density

93 PPI

Response time   (typical)

4 ms (Gray to   Gray)*

Brightness

250  cd/m²

Contrast   ratio (typical)

1000:1

SmartContrast

50,000,000:1

Pixel pitch

0.2745 x   0.2745 mm

Viewing angle

178º (H) /   178º (V)

@ C/R > 10

Flicker-free

Yes

Picture   enhancement

SmartImage

Color gamut   (typical)

NTSC 91%*,   sRGB 107%*

Display   colors

16.7M

Scanning   Frequency

30 - 85 kHz   (H) / 48 - 75 Hz (V)

sRGB

Yes

LowBlue Mode

Yes

EasyRead

Yes

Adaptive sync

Yes

Connectivity

Signal Input

DisplayPort   1.2 x 1, HDMI 1.4 x 1, USB-C 3.2 Gen 2 x 1 (upstream, power delivery up to 65   W)

HDCP

HDCP 1.4   (HDMI/DP/USB-C)

HBR3

Yes

Signal Output

DisplayPort   out* (DP / USB-C)

USB:

USB 3.2 Gen 2   x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)

Audio   (In/Out)

PC audio-in

Headphone out

RJ45

Ethernet LAN   up to 1G*, Wake On Lan

Sync Input

Separate Sync

USB

USB-C

Reversible   plug connector

Super speed

Data and   Video transfer

DP

Built-in   Display Port Alt mode

Power   delivery

USB PD   version 3.0

USB-C max.   power delivery

Up to 65 W   (5V/3A; 9V/3A; 10V/3A; 12V/3A; 15V/3A; 20V/3.25A)

Convenience

Built-in   Speakers

2 W x 2

User   convenience

SmartImage

Input

PowerSensor

Menu

Power On/Off

Control   software

SmartControl

OSD Languages

·          Brazil Portuguese

·          Czech

·          Dutch

·          English

·          Finnish

·          French

·          German

·          Greek

·          Hungarian

·          Italian

·          Japanese

·          Korean

·          Polish

·          Portuguese

·          Russian

·          Simplified Chinese

·          Spanish

·          Swedish

·          Traditional Chinese

·          Turkish

·          Ukranian

Other   convenience

Kensington   lock

VESA mount   (100x100mm)

Plug &   Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 /   8.1 / 8 / 7

Stand

Height   adjustment

150  mm

Pivot

-/+ 90 degree

Swivel

-/+ 180  degree

Tilt

-5 ~ 35  degree

Power

ECO mode

14.6 W (typ.)

On mode

15.2 W (typ.)   (EnergyStar test method)

Standby mode

< 0.5 W   (typ.)

Off mode

Zero watts   with Zero switch

Power LED   indicator

Operation -   White

Standby mode-   White (blinking)

Power supply

Built-in

100-240VAC,   50-60Hz

Dimensions

Product with   stand(max height)

540 x 501 x   205  mm

Product   without stand (mm)

540 x 323 x   51  mm

Packaging in   mm (WxHxD)

600 x 465 x   198  mm

Weight

Product with   stand (kg)

4.98  kg

Product   without stand (kg)

3.40  kg

Product with   packaging (kg)

7.04  kg

Operating   conditions

Temperature   range (operation)

0°C to   40°C  °C

Temperature   range (storage)

-20°C to   60°C  °C

Relative   humidity

20%-80  %

Altitude

Operation:   +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF   (demonstrated)

70,000 hrs   (excluded backlight)

Sustainability

Environmental   and energy

PowerSensor

LightSensor

EnergyStar   8.0

EPEAT*

RoHS

TCO Certified   Edge

Recyclable   packaging material

100  %

Post consumer   recycled plastic

85%

Specific   Substances

PVC / BFR   free housing

Mercury free

Compliance   and standards

Regulatory   Approvals

CE Mark

FCC Class B

SEMKO

CU-EAC

TUV/GS

TUV Ergo

EPA

UKRAINIAN

ICES-003

CB

TUV Eye   Comfort certified

MEPS

RCM

Cabinet

Front bezel

Black

Rear cover

Black

Foot

Black

Finish

Texture
