Standards : | IEEE 802.11ac specification, IEEE 802.11n 2.0 specification, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a. |
Frequency Band : | 2.4GHz and 5GHz concurrent operation |
Maximum Theoretical Throughput : | 300Mbps (2.4GHz), 867Mbps (5GHz) |
Maximum Number of Clients : | 128 |
Deployment options : | Standalone, Web UI. |
Access Point : | Antenna: 3dBi (external) |
Advanced Wireless : | WDS Point-to-point wireless bridge mode, WDS Point-to-multipoint wireless bridge mode. |
Security : | Wired Equivalent Privacy (WEP) Encryption, WiFi Protected Access Pre-shared Key (WPA-PSK, WPA2-PSK), MAC Address filtering, 1 BSSID. |
MAC ACL : | Yes |
VPN Pass-through : | Yes |
802.11e WMM : | (Wireless multimedia mode) for QoS |
Simultaneous Bridge/Client Association : | Yes |
Power : | Country-specific plug: 12V/1.5A (18W), 1.5 Amp power adapter, Power consumption: 8.1W (maximum). |
Mounting : | Desktop standable and Wall mountable |
Physical Interfaces : | Four (4) 10/100/1000BASE-T Ethernet (RJ-45) port with Auto Uplink™ (Auto MDI-X) |
LEDs : | Power, WPS, WiFi, LAN Activity |
Default Reset : | Yes |
Operating Temperature : | 32° to 104°F (0° to 40°C) |
Storage Temperature : | -4° to 158°F (-20° to 70°C) |
Operating Relative Humidity : | 10-90% |
Storage Humidity : | 5-95% |
MTBF : | @ 25°C > 285,000 hours,@ 50°C > 100,000 hours. |
Safety Certification : | CE (EN60950) |
Optional Support : | PMB0351: 5 years OnCall 24x7, PMB0331: 3 years OnCall 24x7, PMB0311: 1 year OnCall 24x7 |
Product Ordering Information : | WAC104-100AUS, WAC104-100NAS, WAC104-100PES, WAC104-100PRS, WAC104-100UKS, WAC104-100INS |
