SPECIFICATIONS: Protocols/Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6 | Network Interfaces | Dual switched auto-negotiation 10/100 Mbps Ethernet ports, integrated PoE | Graphic Display | 132 x 48 (2.41āā) backlit graphical LCD display | Feature Keys | 2 line keys with dual-color LED and support for 4 SIP account, 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 8 dedicated function keys for: MESSAGE(with LED indicator), TRANSFER,HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL | Auxiliary Port | RJ9 headset jack (allowing EHS with Plantronics & Jabra & Sennheiser headsets) | Voice Codecs and Capabilities | Support for G.729A/B, G.711Āµ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB | Telephony Features | Hold, transfer, forward, 5-way conference, call park, call pickup, shared-callappearance(SCA)/bridged-line-appearance(BLA), downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over | HD Audio | Yes, HD handset and speakerphone with support for wideband audio | Base Stand | Yes, 1 angle position available (45Ā°), Wall Mountable (*wall mount sold separately) | QoS | Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS | Security | User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot | Multi-language | English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean, Japanese and more | Upgrade/Provisioning | Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file | Temperature and Humidity | Operation: 0Ā°C to 40Ā°C Storage: -10Ā°C to 60Ā°C Humidity: 10% to 90% Non-condensing | Package Content | GRP2602P phone, handset with cord, base stand, network cable, Quick Installation Guide | Physical | Dimension: 208mm (L) x 180mm (W) x 63.4mm (H) (with handset) Unit weight: 670g; Package weight: 830g |
|
