Dimensions

70.5×44.2×32.8 mm (L×W×H)

Weight

146 g

Waterproof

20 m without the Waterproof Case, 60 m with the Waterproof Case

* Before use, close the battery compartment cover and the USB-C port cover, and tighten the Glass Lens Cover. It is recommended to install the Waterproof Case for long-duration underwater shooting or in environments with high water impact pressure. Osmo Action 5 Pro and its Waterproof Case have an IP68 waterproof rating. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids.

Number of Microphones

3

Touchscreens

Front Screen: 1.46-inch 331 ppi 342×342

800 cd/㎡ max brightness (typical)

Rear Screen: 2.5-inch 326 ppi 400×712

800 cd/㎡ max brightness (typical), 1000 cd/㎡ peak brightness

Supported SD Cards

microSD (up to 1 TB)

Recommended microSD Cards

Recommended Models:

SanDisk Extreme PRO 32GB U3 A1 V30 microSDHC

Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC

Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC

Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC

Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC

Lexar Professional 1066x 64GB U3 A2 V30 microSDXC

Lexar Professional 1066x 128GB U3 A2 V30 microSDXC

Lexar Professional 1066x 256GB U3 A2 V30 microSDXC

Lexar Professional 1066x 512GB U3 A2 V30 microSDXC

Kingston CANVAS Go! Plus 1TB U3 A2 V30 microSDXC

CAMERA

Sensor

1/1.3-inch CMOS

Lens

FOV: 155°

Aperture: f/2.8

Focus Range: 0.35 m to ∞

ISO Range

Photo: 100-25600

Video: 100-51200

Electronic Shutter Speed

Photo: 1/8000-30 s

Video: 1/8000 s to the limit of frames per second

Max Photo Resolution

7296×5472

Zoom

Digital Zoom

Photo: Max 2x

Video: Max 2x

Slow Motion/Timelapse: Not available

Still Photography Modes

Single: Approx. 40 MP

Countdown: Off/0.5/1/2/3/5/10 s

Burst: Up to 30 images/3 seconds

Standard Recording

4K (4:3): 3840×2880@100/120fps

4K (4:3): 3840×2880@24/25/30/48/50/60fps

4K (16:9): 3840×2160@100/120fps

4K (16:9): 3840×2160@24/25/30/48/50/60fps

2.7K (4:3): 2688×2016@100/120fps

2.7K (4:3): 2688×2016@24/25/30/48/50/60fps

2.7K (16:9): 2688×1512@100/120fps

2.7K (16:9): 2688×1512@24/25/30/48/50/60fps

1080p (16:9): 1920×1080@100/120/200/240fps

1080p (16:9): 1920×1080@24/25/30/48/50/60fps

SuperNight

4K (16:9): 3840×2160@24/25/30/48/50/60fps

2.7K (16:9): 2688×1512@24/25/30/48/50/60fps

1080p (16:9): 1920×1080@24/25/30/48/50/60fps

Subject Tracking

2.7K (16:9): 2688×1512@24/25/30/48/50/60fps

2.7K (9:16): 2688×1512@24/25/30/48/50/60fps

1080p (16:9): 1920×1080@24/25/30/48/50/60fps

1080p (9:16): 1920×1080@24/25/30/48/50/60fps

Slow Motion

4K: 4x (120fps)

2.7K: 4x (120fps)

1080p: 8x (240fps), 4x (120fps)

Hyperlapse

4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30

Timelapse

4K/2.7K/1080p@25/30fps

Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s, 1/2/5/30/60 mins

Duration: 5/10/20/30 mins, 1/2/3/5 hours, ∞

Stabilization

EIS:

RockSteady 3.0

RockSteady 3.0+

HorizonBalancing

HorizonSteady

* EIS is not supported in Timelapse and Slow Motion modes. HorizonSteady is only available when the video resolution is 1080p (16:9) or 2.7K (16:9) with a frame rate of 60fps or below. HorizonBalancing is only available when the video resolution is 1080p (16:9), 2.7K (16:9), or 4K (16:9) with a frame rate of 60fps or below.

Pre-Rec

Pre-Recording Duration: 5/10/15/30 s, 1/2/5 mins

Max Video Bitrate

120 Mbps

Supported File System

exFAT

Photo Format

JPEG/RAW

Video Format

MP4 (HEVC)

Built-in Storage Capacity

The camera features 64 GB of built-in storage, with 47 GB available for use. The storage capacity can be expanded by inserting a microSD card.

Audio Recording

48 kHz 16-bit; AAC

BATTERY

Type

Li-ion 1S

Capacity

1950 mAh

Energy

7.5 Wh

Voltage

3.87 V

Operating Temperature

-20° to 45° C

Charging Temperature

5° to 40° C

Operating Time

240 mins

* Measured at a room temperature of 25° C, while recording 1080p/24fps (16:9) video, with RockSteady on, Wi-Fi off, and screens off. Data was collected in a controlled environment. Please refer to your actual experience.

CONNECTION

Wi-Fi Operating Frequency

2.400-2.4835 GHz

5.150-5.250 GHz

5.725-5.850 GHz

Wi-Fi Protocol

Wi-Fi 6.0

802.11 a/b/g/n/ac/ax

Wi-Fi Transmitter Power (EIRP)

2.4 GHz: < 23 dBm (FCC), < 20 dBm (CE/SRRC/MIC)

5.1 GHz: < 23 dBm (FCC/CE/SRRC/MIC)

5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE)

Bluetooth Operating Frequency

2.400-2.4835 GHz

Bluetooth Transmitter Power (EIRP)

< 13 dBm

Bluetooth Protocol

BLE 5.1
