Accessory Port

Cold Shoe

1/4"-20 Threaded Hole

USB-C Firmware Update Port (Power/USB)

USB-C Data Port (Power/CVBS/CAN)

Image Sensor

Resolution: 1920×1440

FOV:

‌57.4° (horizontal), 44.6° (vertical), 70.1° (diagonal)

Frame Rate: 30fps

Equivalent Focal Length: 30 mm

ToF Sensor

Ranging Points: 76,800

Sensing Range: 0.5-20 m

FOV:

Wide-Angle Mode: 65° (horizontal), 40° (vertical), 76.1° (diagonal)

Telephoto Mode: 20° (horizontal), 20° (vertical), 28.3° (diagonal)

Frame Rate: 30fps

Equivalent Focal Length: 30 mm (wide-angle mode)

Ranging Accuracy: ±1% to 3% (affected by the distance)

Machine Learning

Tracking Subject: Can recognize up to five subjects at the same time, and choose one to follow

Smart Object Identification: Human, vehicle

Focus Area: Flex Spot (activate focus lock by framing the subject and pressing the trigger; supports autofocus only, not ActiveTrack); Wide (when subject-locked on human, supports both autofocus and ActiveTrack*; when   subject-locked on vehicle, supports autofocus only, not ActiveTrack)

* ActiveTrack is available only when used in conjunction with DJI RS 4 Pro or DJI RS 3 Pro.‌

Electrical Properties

‌Power Consumption: Average approx. 6.3 W, max 6.8 W

Input Voltage: 6.6-17.2 V

Operating Temperature

-20° to 45° C (-4° to 113° F)

Mechanical Properties

Main Body Dimensions: Approx. 68×25×57 mm (L×W×H)

Weight: Approx. 140 g (0.31 lbs)

Mounting Method and Position

Can be mounted directly via cold shoe or using the 1/4" threaded hole

* It is recommended to mount the DJI Focus Pro LiDAR close to the camera's optical axis.

GRIP

Operating Frequency

2.400-2.4835 GHz

Bluetooth Transmitter Power

< 8 dBm

Mechanical Properties

Main Body Dimensions: Approx. 59×73×162 mm (L×W×H)

Main Body Weight: Approx. 482 g (1.06 lbs)

Mounting Method

Flexible mounting on either left or right side of the cage via NATO port

Screen

1.8-inch full-color touchscreen

Port

USB-C Port (DJI Focus Pro LiDAR)

USB-C Port (DJI Focus Pro Motor)

USB-C Port (Camera Control Port)

USB-C Port (Battery Charging Port)

Operating Time

‌Approx. 2.5 hours

* Measured in a 25° C (77° F) environment while simultaneously powering the grip screen, LiDAR, and a focus motor, with AF continuously on, and paired with a manual lens.

Charging Power

Supports 18W PD fast charging

Battery Model

BHX711-3000-7.2V

Power Supply Voltage

6.6-8.4 V

Operating Temperature

-20° to 45° C (-4° to 113° F)

HAND UNIT

Operating Frequency

2.400-2.4835 GHz

Bluetooth Transmitter Power

< 8 dBm

2.4GHz Transmitter Power (EIRP)

‌< 20 dBm (CE/SRRC/MIC)

< 26 dBm (FCC)

2.4GHz Transmission Distance

160 m*

100 m**

‌* Measured under FCC standard in an unobstructed environment free of interference.

‌‌‌‌** Measured under CE/SRRC/MIC standards in an unobstructed environment free of interference.

Mechanical Properties

‌Dimensions: Approx. 128×87×87 mm (L×W×H)

Weight: Approx. 555 g (1.22 lbs) (without battery)

Battery

Model: NP-F550

Input: 6.3-8.4 V

Dimensions: 71×38.6×21.1 mm (L×W×H)

Screen

1.09-inch full-color touchscreen

Static Power Consumption

0.83 W

Operating Temperature

-20° to 45° C (-4° to 113° F) (excluding battery temperature)

MOTOR

2.4GHz Transmitter Power (EIRP)

‌< 20 dBm (CE/SRRC/MIC)

< 26 dBm (FCC)

2.4GHz Transmission Distance

160 m*

100 m**

‌* Measured under FCC standard in an unobstructed environment free of interference.

‌‌‌‌** Measured under CE/SRRC/MIC standards in an unobstructed environment free of interference.

Mechanical Properties

‌Dimensions: Approx. 100×61×34 mm (L×W×H)

‌Weight: Approx. 123 g (0.27 lbs)

Rod Diameter: 15 mm

Output Gear Teeth: 30

Output Gear Module: 0.8

Performance

Max Torque: 0.6 N·m (8 V)

Max Speed: 300 rpm (8 V)

Power Supply Voltage

6.6-17.2 V

Stall Current

2 A, 8 V

Free Current

60 mA, 8 V

Operating Temperature

-20° to 45° C (-4° to 113° F)

Output Voltage

6.6-17.2 V
