GENERAL |
|
Phase | Single Phase |
Form Factor | Rackmount, Tower |
UPS Topology | Line-interactive |
Energy Saving Technology | GreenPower UPS⢠Bypass Technology |
Energy Star Qualified | Yes |
Active PFC Compatibility | Yes |
INPUT |
|
Nominal Input Voltage ( Vac ) | 220 230 240 |
Input Voltage Range ( Vac ) | 159 ~ 288 |
Adjustable Voltage Range ( Vac ) | 151 ~ 302 Vac |
Input Frequency ( Hz ) | 50 ± 3 60 ± 3 |
Input Frequency Detection | Auto-sensing |
Rated Input Current ( A ) | 10 |
Input Connector Type | IEC C14 ã |
Detachable Power Cord Plug Type | AU x 1 ã |
Power Cord Length (ft.) | 10 |
Power Cord Length (m.) | 3 |
OUTPUT |
|
Capacity (VA) | 1500 |
Capacity (Watts) | 1500 |
On Battery Waveform | Pure Sine Wave |
On Battery Voltage(s) ( Vac ) | 220 ± 5 % 230 ± 5 % 240 ± 5 % |
On Battery Frequency ( Hz ) | 50 ± 1% 60 ± 1% |
Power Factor | 1 |
Automatic Voltage Regulation (AVR) | Double Boost, Single Buck |
Overload Protection | Internal Current Limiting, Circuit Breaker |
Outlet(s) - Total | 10 |
Outlet Type | IEC C13 x 10 ã |
Outlet(s) - Battery & Surge Protected | 10 |
Outlet(s) - Critical Load (CL) | 5 |
Outlet(s) - Non-Critical Load (NCL) | 5 |
Typical Transfer Time ( ms ) | 4 |
BATTERY |
|
Runtime at Half Load ( min ) | 18.6 |
Runtime at Full Load ( min ) | 6 |
Typical Recharge Time ( Hours ) | 3 |
Start On Battery | Yes |
Built-in Battery Management Module | Yes |
User-replaceable | Yes |
Hot-swappable | Yes |
Battery Type | Sealed Lead-acid |
Battery Cartridge (RBP) | RBP0129 |
Battery Cartridge (RBP) Quantity ( pcs ) | 1 |
Battery Quantity (Each RBP) ( pcs ) | 4 |
SURGE PROTECTION & FILTERING |
|
Surge Suppression ( Joules ) | 2430 |
EMI/RFI Filtration | Yes |
Network Protection RJ45 | 1-in, 1-out |
MANAGEMENT & COMMUNICATIONS |
|
LCD Panel | Yes |
LCD Orientation | Rotatable LCD â Manual |
LCD Information Display | Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log |
LCD Setting & Control | Mode Setting, Alarm Setting, Input & Output, Battery Setting, Communication |
LED Indicators | Power On, Line Mode, Battery Mode, UPS Fault, Night Mode |
HID Compliant USB Port(s) | 1 |
Dry Contact (with Relay) | Yes |
Emergency Power Off (EPO) Port | Yes |
Audible Alarms | Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault |
Management Cable ( pcs ) | Power Cord x3, USB Cable x1, Serial Cable x1, EPO Cable x1, Phone Line x1 |
Ethernet Data Transmission Speed | Up to 1Gbps |
Power Management Software | PowerPanel Business (Recommended) |
PowerPanel Cloud Service | Yes - 90 Days Free Trial with PowerPanel Personal/Business |
PHYSICAL |
|
Enclosure Construction | Metal |
Color | Black |
Rackmount Rail | Yes |
Rackmount Ears | Yes |
PHYSICAL SIZE - UPS MODULE |
|
Dimensions (WxHxD) (in.) | 17.1 x 3.4 x 16.2 |
Dimensions (WxHxD) (mm.) | 433 x 86.5 x 412 |
Weight (lbs.) | 54.2 |
Weight (kg.) | 24.6 |
Installed Rack Height ( U ) | 2 |
ENVIRONMENTAL |
|
Operating Temperature (°F) | 32 ~ 104 |
Operating Temperature (°C) | 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % ) | 0 ~ 95 |
Operating Elevation ( feet/meters ) | 0-9,843 feet (0-3,000 meters) |
Storage Temperature (°F) | 5 ~ 113 |
Storage Temperature (°C) | -15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % ) | 0 ~ 95 |
Storage Elevation ( feet/meters ) | 0-49,213 feet (0-15,000 meters) |
Online Thermal Dissipation ( BTU/hr ) | 75.1 |
Audible Noise at 1.0M from Surface of Unit | 38.5~52.5 |
CERTIFICATIONS |
|
Certifications | CE, FCC Class B, UL, cUL, RCM, VCCI, UKCA |
RoHS | Yes |
OTHERS |
|
Whatâs in the Box | PR1500ERT2U UPS Rackmount Rail Rackmount Ears Rail Kit Screw Kit Power Cord USB Cable Serial Cable EPO Cable Phone Line User's Manual * Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide. |
